Porsche 356 / Lever-Pedal

356 — HAND-BRAKE-001

356 — HAND-BRAKE-001
356 — HAND-BRAKE-001
Filtra per variante:
# Codice Descrizione Qtà Variante
1 644 24 023 HAND BRAKE CABLECOMPLETE /LL 1
(1) 644 24 024 HAND BRAKE CABLECOMPLETE /RL 1
2 644 24 025 HAND BRAKE CABLE /LL 1
(2) 644 24 026 HAND BRAKE CABLE /RL 1
3 644 24 215 PULL HANDLE 1
4 900 095 001 00 PIN2 X 14 1
5 644 24 027 GUIDE TUBE 1
6 644 24 228 LOCKING PIECE 1
7 644 24 233 WASHER 1
8 644 24 229 PRESSURE SPRING 1
9 644 24 231 GUIDE BUSH 1
10 644 24 241 PRESSURE RING 1
11 644 24 216 RUBBER RING 1
12 900 151 006 02 WASHERB 6,4 2
13 900 028 009 01 SPRING WASHERB 6 2
14 900 076 010 01 HEXAGON NUTM 6 2
15 900 088 001 00 BOLT5 H 11 X 18 X 15 1
16 900 025 003 00 WASHER5,3 1
17 900 021 001 00 COTTER PIN1,5 X 8 1
18 695 424 057 00 LEVER /LL 1
(18) 695 424 058 00 LEVER /RL 1
19 644 24 207 BUSH 2
20 644 24 021 BEARING BRACKET /LL 1
(20) 644 24 021 1 BEARING BRACKET /RL 1
21 000 97 310 O-RING 2
22 644 24 206 CLIP 1
23 900 027 014 01 LOCK RINGB 6 2
24 900 076 010 02 HEXAGON NUTM 6 2
25 644 24 208 HAND BRAKE CABLE 1
26 356 23 213 ADJUSTING NUT 1
27 900 076 010 02 HEXAGON NUTM 6 1
28 356 23 204 SEALING BELLOWS 1
29 356 24 308 CONNECTING PIECE 1
30 356 24 309 CLIP 1
31 644 424 531 00 RETURN SPRING 1
32 644 24 238 HAND BRAKE CABLE 2
33 644 424 575 00 SLEEVE10 MM 2
(33) 644 424 575 01 SLEEVE18 MM X
34 644 424 571 00 LOCKING NUT 2
35 644 025 820 00 SUSPENSION STRAP 2
36 900 075 011 02 BOLT HEX-HD.M 6 X 15 2
37 900 075 016 02 BOLT HEX-HD.M 6 X 22 2
38 900 028 008 01 SPRING WASHERB 6 2
39 900 076 010 02 HEXAGON NUTM 6 2
