Electrical System, Instruments & Dashboard
356 — DRIVING-MECHANISMREVOLUTION-COUNTER
Compatible with
Components
| No. | Part Number | Description | Qty. | Model |
|---|---|---|---|---|
| 1 | 547 18 002 | DRIVING MECHANISMREVOLUTION COUNTERCOMPLETE | 1 | |
| 2 | 547 18 101 | HOUSING | 1 | |
| 3 | 547 18 103 | THRUST WASHER0,8 MM | X | |
| - | 547 18 104 | THRUST WASHER0,6 MM | X | |
| - | 547 18 105 | THRUST WASHER0,5 MM | X | |
| 4 | 547 18 108 | DRIVE SHAFT | 1 | |
| 5 | 900 123 010 30 | SEALING RINGALUMINIUMA 20 X 24 | 2 | |
| 6 | 547 18 106 | PRESSURE SCREW | 1 | |
| 7 | 369 05 704 1 | SEALING RINGFILZ | 1 | |
| 8 | 369 05 718 | THRUST WASHER0,8 MM | X | |
| - | 369 05 719 | THRUST WASHER0,6 MM | X | |
| - | 369 05 720 | THRUST WASHER0,5 MM | X | |
| 9 | 547 18 107 | PINION SHAFT | 1 | |
| 10 | 369 05 703 | PRESSURE SCREW | 1 |
