Engine

356 — CRANKCASEM-001

Compatible with

356
Porsche 356, schema ricambi: Crankcasem 001

Components

No. Part Number Description Qty. Model
- 539 01 001 10 CRANKCASEWITHHOUSING COVERWITHBEARING4ANDWITH STUDSM 22 001 >> 22 489M 50 101 >> 50 162M 33 901 >> 35 794M 41 001 >> 41 425M 60 001 >> 67 000M 80 001 >> 81 200 1 13001300 S15001500 S16001600 S
- 616 01 001 10 CRANKCASEWITHHOUSING COVERWITHBEARING4ANDWITH STUDSM 67 001 >> 68 897M 81 201 >> 81 707 1 16001600 S
- 616 01 001 20 CRANKCASEWITHHOUSING COVERWITHBEARING4ANDWITH STUDSM 68 898 >> 73 326M 81 708 >> 83 424 1 16001600 S
- 616 010 001 21 CRANKCASEWITHHOUSING COVERWITHBEARING4ANDWITH STUDSM 73 237 >>M 83 425 >> 1 16001600 S
1 900 061 008 02 STUDBM 8 X 25FORCOVERCAMSHAFT 2
2 900 074 042 02 BOLT HEX-HD.M 8 X 60 7
3 539 01 132 COVERFORCAMSHAFT 1
4 539 01 118 STUD 16
5 528 01 107 BOLT HEX-HD.TENSIONING DEVICEFORCRANKCASE539. 01.001.10 1
- 528 01 107 BOLT HEX-HD.TENSIONING DEVICEFORCRANKCASE616. ... 1
6 999 701 006 40 O-RING 7
7 369 01 111 WASHER$ 10COPPER 7
8 999 070 004 02 CAP NUT 6
9 539 01 114 STUDFORFASTENINGTRANSMISSION 2
10 900 074 047 02 BOLT HEX-HD.M 8 X 90 1
11 900 028 010 01 SPRING WASHERB8 10
12 900 076 013 02 HEXAGON NUTM 8 10
13 539 01 133 DRAIN PLUG 1
(14) 539 01 123 RUBBER SEALOIL DUCTCRANKCASE539. 01.001.10 2
14 616 01 123 RUBBER SEALOIL DUCTCRANKCASE616. ... 2
15 539 01 122 RUBBER SEALFOROIL DUCT 1
(16) 539 07 729 GUIDE TUBE178 MMCRANKCASE539. 01.001.10 1
(16) 539 07 076 GUIDE TUBEOIL LEVEL DIPSTICK225 MMCRANKCASE539.01.001.10 1
- 999 701 006 40 SEALING RINGGUIDE TUBECRANKCASE539. 01.001.10 1
16 539 07 748 GUIDE TUBEOIL LEVEL DIPSTICK225 MMCRANKCASE616. ... 1
17 999 012 006 00 DOWEL PIN 2
18 000 95 105 STUD 10
19 000 95 106 STUD 1
20 539 01 119 STUDFORCRANKCASE539. 01.001.10 4
21 900 105 001 02 SCREW SOCKETLL 6 M 1
22 999 113 029 50 RADIAL SHAFT SEALDG 60 X 80 X 10/1 1
23 702 101 195 00 FITTED SLEEVE 2
24 539 01 110 DOWEL PIN 4
25 616 01 121 OIL TUBE 1
25 616 101 377 00 OIL TUBE 1
25 616 101 377 OIL TUBE 1
26 539 01 112 STUD 11
27 900 025 02 WASHER6,4 10
28 900 028 008 01 SPRING WASHERB 6 10
- 900 025 004 02 WASHER6,4 10
29 900 076 010 02 HEXAGON NUTM 6 10
30 616 101 039 00 OIL DRAIN LID 1
31 539 01 150 OIL DRAIN LID 1
32 616 101 333 00 FILTER INSERT 1
33 900 055 013 20 RIVET5 X 12 1
34 539 01 152 GASKET 2
35 539 01 151 OIL STRAINER 1
(36) 616 01 124 GASKETCRANKCASE539. 01.001.10 1
36 616 01 124 1 GASKETCRANKCASE616. ... 1
37 616 01 114 OIL TUBECRANKCASE616. 01.147.2 1
38 616 01 115 PLUGCRANKCASE616. 01.147.2 2
39 - COVERNOT AVAILABLEWHEN REQUIRED ORDER ALSO:CRANKCASE539. 01.001.10 1
(39) 616 01 147 2 COVER 1
40 900 028 010 01 SPRING WASHERB 8 11
41 502 08 310 HEXAGON NUTM 8 11
42 539 01 112 STUD 4
43 999 113 012 50 SHAFT SEALDG 48 X 65 X 10/1 1
44 539 01 106 GASKETCRANKCASE539. 01.001.10 1
45 539 01 154 COVERCRANKCASE539. 01.001.10 1
46 539 01 125 GASKET 1
47 900 028 010 01 SPRING WASHERB 8 4
48 900 074 037 02 BOLT HEX-HD.M 8 X 35 4
49 539 01 145 BRACKET 1
50 539 01 115 SCREWFORBEARING4 1
51 900 028 010 01 SPRING WASHERB 8 1
(52) 616 01 116 STUDFUEL PUMPCRANKCASE616. ... 2
52 900 061 044 01 STUDFUEL PUMPCRANKCASE539. 01.001.10 2
53 539 01 116 STUDDISTRIBUTORCRANKCASE539. 01.001.10 1
(53) 616 01 117 STUDDISTRIBUTORCRANKCASE616. ... 1
54 999 061 017 02 STUDBM 8 X 30 2
55 900 028 010 01 SPRING WASHERB 8 2
56 900 076 013 02 HEXAGON NUTM 8 2
