Components
| No. | Part Number | Description | Qty. | Model |
|---|---|---|---|---|
| 1 | 692 101 005 01 | CRANKCASECOMPLETE | 1 | |
| 2 | 547 01 129 | STUD | 6 | |
| 3 | 900 123 004 30 | SEALING RINGA 10 X 16 X 1COPPER | 6 | |
| 4 | 999 070 004 02 | CAP NUT | 6 | |
| 5 | 900 074 038 02 | BOLT HEX-HD.M 8 X 60 | 2 | |
| 6 | 900 074 042 02 | BOLT HEX-HD.M 8 X 60 | 6 | |
| 7 | 900 074 047 02 | BOLT HEX-HD.M 8 X 90 | 2 | |
| 8 | 900 074 037 02 | BOLT HEX-HD.M 8 X 35 | 2 | |
| 9 | 900 074 043 00 | STUDM 8 X 65 | 1 | |
| 10 | 547 01 140 | DOWEL PIN | 2 | |
| 11 | 900 028 010 00 | SPRING WASHERB 8 | 13 | |
| 12 | 502 08 310 | HEXAGON NUT | 15 | |
| 13 | 900 061 026 00 | STUDM 8 X 22 | 2 | |
| 14 | 900 012 033 00 | DOWEL PIN3 H 8 X 10 | 3 | |
| 15 | 547 01 104 1 | HOUSING | 1 | |
| - | 900 012 032 00 | DOWEL PIN3 H 8 X 8 | 1 | |
| 16 | 999 039 001 00 | LOCK PLATE | 2 | |
| 17 | 900 061 023 00 | STUDM 8 X 15 | 2 | |
| 18 | 900 061 024 00 | STUDM 8 X 18 | 2 | |
| 19 | 900 061 031 00 | STUDM 8 X 40 | 2 | |
| 20 | 547 01 133 | STUD | 2 | |
| 21 | 547 01 137 | STUD | 2 | |
| 22 | 547 01 128 | STUD | 16 | |
| 23 | 547 01 118 | THREADED BUSH | 4 | |
| 24 | 539 01 108 | PLUG | 2 | |
| 25 | 539 01 111 | PLUG | 4 | |
| 26 | 547 01 116 | PLUG | 1 | |
| 27 | 547 01 130 | DOWEL PIN | 3 | |
| 28 | 547 01 131 | NOZZLEI | 1 | |
| 29 | 547 01 132 | NOZZLEII | 2 | |
| 30 | 547 01 136 | NIPPLEOIL PRESSURE SWITCH | 1 | |
| (30) | 900 065 002 00 | SCREWM 14 X 1,5 | 1 | |
| 31 | 900 123 007 20 | SEALING RINGA 14 X 18COPPER | 1 | |
| 32 | 539 01 123 | SEALING RING | 1 | |
| 33 | 900 123 009 30 | SEALING RINGALUMINIUMA 18 X 24 X 1,5 | 3 | |
| 34 | 547 07 112 | DRAIN PLUG | 1 | |
| 35 | 547 07 130 | OIL STRAINER | 1 | |
| 36 | 547 07 143 | STRAINER | 1 | |
| 37 | 547 07 142 | STRAINER | 1 | |
| 38 | 900 075 011 00 | BOLT HEX-HD.M 6 X 15 | 3 | |
| 39 | 900 025 005 00 | WASHER6,4 X 14 X 1,5 | 3 | |
| 40 | 900 027 013 00 | LOCK RINGB 6 | 3 | |
| 41 | 900 076 010 00 | HEXAGON NUTM 6 | 3 | |
| 42 | 616 107 511 00 | PISTONRELIEF VALVE | 2 | |
| 43 | 547 07 113 | SPRINGRELIEF VALVE | 2 | |
| 44 | 999 064 009 02 | SCREWRELIEF VALVE | 2 | |
| 45 | 547 01 108 | BUSH | 1 | |
| 46 | 547 01 138 | O-RING | 1 | |
| 47 | 547 01 135 | BREATHER | 1 | |
| 48 | 900 075 011 00 | BOLT HEX-HD.M 6 X 15 | 1 | |
| 49 | 900 025 004 00 | WASHER6,4 | 4 | |
| 50 | 900 027 013 00 | LOCK RINGB 6 | 2 | |
| 51 | 900 076 010 00 | HEXAGON NUTM 6 | 2 | |
| 52 | 547 01 107 | CAP | 1 |
