Fuel & Exhaust

356 — CARBURETORPALLAS-ZENIT-32NDIXANDFUEL-INTAKE-LINE

Compatible with

356
Porsche 356, schema ricambi: Carburetorpallas zenit 32ndixandfuel intake line

Components

No. Part Number Description Qty. Model
- 616 108 902 01 SET OF SEALSFORCARBURETOR 2
1 616 08 141 CARBURETOR32 NDIX (PO 3 L) 1 1600
(1) 616 08 141 1 CARBURETOR32 NDIX (PO 3 R) 1 1600
(1) 616 08 142 CARBURETOR32 NDIX (PO 2 L) 1 1600 S
(1) 616 08 142 1 CARBURETOR32 NDIX (PO 2 R) 1 1600 S
2 597 108 310 00 GASKET 2
3 616 08 013 LEVER 1
(3) 616 08 034 LEVER 1
4 616 08 139 BRACKET 2
5 616 08 119 TENSION SPRING 2
6 616 08 011 REVERSE LEVER 1
7 999 167 001 00 BALL PINA 10 2
8 900 025 004 02 WASHER6,4 3
9 900 028 008 01 SPRING WASHERB 6 2
10 900 076 010 02 HEXAGON NUTM 6 2
11 616 08 017 REVERSE LEVER 1
12 900 025 004 02 WASHER6,4 1
13 900 021 002 00 COTTER PIN1,5 X 10 1
14 616 08 012 PUSH ROD 2
15 N 011 005 14 HEXAGON NUTM 5 6
16 900 076 029 02 HEXAGON NUTM 5LEFT THREAD 2
17 N 015 521 3 BALL SOCKETA 8 4
18 900 169 010 02 BALL SOCKETA 8LEFT THREAD 2
19 616 08 131 PUSH ROD 1
20 527 08 801 OIL WETTED AIR CLEANER 2 1600
21 616 08 814 1 AIR CLEANER 2 1600 S
- 999 701 093 50 O-RING 1 1600 S
22 616 08 811 1 FILTER INSERT 2 1600 S
- 616 108 911 00 RUBBER SEALFORFILTER INSERT 2 1600 S
23 616 08 035 INTAKE MANIFOLD 2
24 900 061 006 02 STUDBM 8 X 20 8
25 502 08 110 GASKET 2
26 900 074 044 02 BOLT HEX-HD.M 8 X 70 2
27 900 076 013 02 HEXAGON NUTM 8 4
28 900 028 010 01 SPRING WASHERB 8 14
29 502 08 310 HEXAGON NUT 8
30 616 08 042 1 INTERMEDIATE FLANGE 1
(31) 539 08 402 GASKETM >> 73 236M >> 83 423 1 16001600 S
31 999 701 043 50 O-RINGM 73 237 >>M 83 424 >> 1 16001600 S
32 539 08 408 CAM FOLLOWER 1
33 616 108 440 00 FLANGEWITHGASKET 1
34 900 028 010 01 SPRING WASHERB 8 4
35 502 08 310 HEXAGON NUT 2
36 616 08 401 FUEL PUMP 1
37 900 074 081 01 BOLT HEX-HD.M 8 X 30 2
38 616 08 022 1 FUEL LINE 1
39 539 08 201 NIPPLE 1
40 900 193 001 02 CAP SCREWAL 8 1
41 546 08 202 UNION 1
42 900 123 005 60 SEALING RINGA 12 X 16 1
43 616 108 432 00 HOLLOW SCREW 2
44 616 108 423 00 SEALING RING 6
45 616 100 867 00 HOLLOW SCREW 1
46 616 08 021 2 FUEL LINE 1
