Suspension, Steering & Axles, Transmission & Clutch
914 — TRANSMISSION_COVERTRANSMISSION_SUSPENSION
On request
Components
| No. | Part Number | Description | Qty. | Model |
|---|---|---|---|---|
| 1 | 644 332 221 00 | REAR WHEEL SHAFT | 2 | 356 A/540.1 |
| 2 | 900 052 005 00 | BALL BEARING6210 | 1 | |
| 3 | 519 32 103 | SPACER | X | |
| 4 | 519 32 206 | SPACER RING2,9 MM | X | |
| (4) | 519 32 207 | SPACER RING3,0 MM | X | |
| (4) | 519 32 208 | SPACER RING3,1 MM | X | |
| (4) | 519 32 209 | SPACER RING3,2 MM | X | |
| (4) | 519 32 210 | SPACER RING3,3 MM | X | |
| (4) | 519 32 211 | SPACER RING3,4 MM | X | |
| (4) | 519 32 212 | SPACER RING3,5 MM | X | |
| (4) | 519 32 213 | SPACER RING3,6 MM | X | |
| (4) | 519 32 214 | SPACER RING3,7 MM | X | |
| (4) | 519 32 215 | SPACER RING3,8 MM | X | |
| (4) | 519 32 216 | SPACER RING3,9 MM | X | |
| (4) | 519 32 217 | SPACER RING4,0 MM | X | |
| (4) | 519 32 218 | SPACER RING4,1 MM | X | |
| (4) | 519 32 219 | SPACER RING4,2 MM | X | |
| (4) | 519 32 220 | SPACER RING4,3 MM | X | |
| (4) | 519 32 221 | SPACER RING4,4 MM | X | |
| (4) | 519 32 222 | SPACER RING4,5 MM | X | |
| 5 | - | RING GEAR AND PINION SHAFTSEE GROUP3/03/00ILL.17 | 1 | |
| 6 | 519 32 101 | HOUSING | 1 | |
| - | - | 1 SETREAR WHEEL SHAFTANDDIFFERENTIAL PINIONSSP 54 | 1 | 356 |
| 7 | 644 332 043 00 | DIFFERENTIAL PINIONS1 SET | 1 | 356 A/540.1 |
| 8 | 644 332 401 00 | BEVEL GEAR | 2 | 356 A/540.1 |
| 9 | 519 32 102 | DIFFERENTIAL BOLT | 1 | |
| (10) | - | GUIDE PIECE32 05 2 | 4 | 356 |
| 10 | 644 321 231 02 | GUIDE PIECE | 4 | 356 A/540.1 |
| (10) | 644 321 231 03 | GUIDE PIECEOVERSIZE | X | 356 A/540.1 |
| (11) | - | HOUSING COVER32 09 1 | 1 | 356 |
| 11 | 644 332 215 00 | HOUSING COVER | 1 | 356 A/540.1 |
| 12 | 900 053 004 00 | BALL BEARING7210 | 1 | |
| (13) | 519 32 105 | LOCK PLATE | 3 | 356 |
| 13 | 741 332 281 00 | LOCK PLATE | 3 | 356 A/540.1 |
| (14) | 519 32 205 | BOLT HEX-HD. | 6 | 356 |
| 14 | 741 332 271 05 | BOLT HEX-HD. | 6 | 356 A/540.1 |
| 15 | 519 32 104 | PIN | 1 |
