Components
| No. | Part Number | Description | Qty. | Model |
|---|---|---|---|---|
| 1 | 914 571 907 00 | FRESH AIR INLET BOX | 6 | |
| 1/1 | 914 571 905 10 | TENSION SPRING | 6 | |
| (2) | 914 571 904 10 | SEALINGF >>47329 24928 | 1 | |
| 2 | 914 571 129 10 | SEALINGF 47329 24929>> | 1 | 914-1,7/1,8V914-1,8/2,0 |
| 2/1 | 914 571 131 10 | GRILLEF 47329 24929>> | 1 | 914-1,7/1,8V914-1,8/2,0 |
| 3 | 900 151 006 02 | WASHERB 6,4 | 2 | |
| 4 | 900 075 015 02 | BOLT HEX-HD.M 6 X 20 | 2 | |
| 5 | 999 512 165 02 | HOSE CLIP | 2 | |
| - | PCG 571 900 00 | WATER DRAIN HOSE | * | |
| 6 | - | 75 MM | 1 | |
| 7 | 914 571 156 10 | WATER DRAIN HOSE | 1 | |
| 8 | 914 571 153 10 | T - PIECEWATER DRAIN HOSE | 1 | |
| - | PCG 571 900 00 | WATER DRAIN HOSE | * | |
| 9 | - | 400 MM | ||
| 10 | 911 571 044 32 | FAN HOUSINGWITHENGINEANDFAN | 1 | |
| 10/1 | 901 571 922 00 | SEALING RINGFAN HOUSINGENGINE | 1 | |
| - | 911 571 320 32 | BLOWER MOTORWITHFAN | 1 | |
| 11 | 900 075 002 02 | BOLT HEX-HD.M 5 X 10 | 2 | |
| 12 | 900 027 003 01 | LOCK RINGB 5 | 4 | |
| 13 | 900 025 003 02 | WASHER5,3 | 2 | |
| 14 | 999 512 128 02 | HOSE CLIP | 8 | |
| 14 | 999 512 128 02 | HOSE CLIP | 4 | 914-1,8V/1,8914-2,0 |
| 15 | 914 571 123 10 | CONNECTING HOSE | 2 | |
| 16 | 914 571 149 10 | CONTROL BOX | 1 | |
| 17 | 914 571 150 10 | CONTROL BOX | 1 | |
| 18 | 901 571 919 00 | CLIP | 7 | |
| 19 | 914 572 123 10 | AIR HOSE | 2 | |
| 20 | 914 572 913 10 | SEALING RING | 2 | |
| 21 | 914 571 348 10 | AIR DISTRIBUTOR | 2 | 914-6/4 |
| 22 | 914 571 113 10 | RETAINING CLIP | 4 | |
| 23 | 900 025 003 02 | WASHER5,3 | 4 | |
| 24 | 900 076 004 02 | HEXAGON NUTM 5 | 4 | |
| 25 | 914 571 118 10 | BOWDEN CABLE | 2 | |
| 26 | 914 572 045 10 | DEFROSTER NOZZLE | 1 | 914-6/4 |
| 27 | 914 572 046 10 | DEFROSTER NOZZLE | 1 | 914-6/4 |
| 28 | 914 572 157 10 | SEALING RINGFORDEFROSTER NOZZLE | 2 | |
| 29 | 999 512 162 02 | CLAMPING SPRING | 4 | |
| 30 | 999 512 133 02 | HOSE CLIP | 2 | 914-6/4 |
| 31 | 914 572 127 10 | HEATER HOSE | 1 | 914-6/4 |
| 31/1 | 914 572 189 10 | COVERFORDEFROSTER NOZZLECENTER | 1 | 914-4 |
| 32 | 914 613 111 10 | SWITCH | 1 | |
| 33 | 901 571 917 00 | KNOBBLACK | 2 | |
| 33 | 901 571 918 00 | KNOBRED | 1 | |
| - | 900 631 129 90 | BULB12 V 1,2 WFORILL.32 | 1 | |
| 34 | 900 075 015 02 | BOLT HEX-HD.M 6 X 20 | 1 | |
| 35 | 900 028 008 01 | SPRING WASHERB 6 | 1 | |
| 36 | 900 025 004 02 | WASHER6,4 | 1 | |
| 37 | 914 571 151 10 | RUBBER GROMMETFORBOWDEN CABLE | 1 | |
| - | 914 571 115 10 | BOWDEN CABLEFORBLOWER | 1 | |
| - | 914 571 116 10 | BOWDEN CABLECOLD AIR | 1 | |
| - | 914 571 117 10 | BOWDEN CABLEHOT AIR | 1 |
