Components
| No. | Part Number | Description | Qty. | Model |
|---|---|---|---|---|
| 1 | 022 119 031 | IMPELLERWITHPULLEYANDHUBM >> W0 170 000 | 1 | 914-4/1,7 |
| (1) | 021 119 031 AD | IMPELLERWITHPULLEYANDHUBM GB0 000 001>>M AN0 000 001>>M W0 170 001 >>M >> W0 250 000 | 1 | |
| 2 | 021 119 119 | HUB | 1 | |
| 3 | 021 119 121 | SPACER | 1 | |
| 4 | 021 119 125 A | SEALING RING | 1 | |
| 5 | N 014 326 1 | BOLT HEX-HD.M 8 X 30SELFLOCKING | 1 | |
| (6) | 021 119 127 | CHEESE-HD. SCREWM 8 X 39M >> W0 170 000 | 3 | 914-4/1,7 |
| 6 | N 010 246 4 | BOLT HEX-HD.M 8 X 45M >> W0 250 000 | 3 | 914-1,7/1,8V914-1,8/2,0 |
| 7 | N 012 241 11 | SPRING WASHERB 8 X 15 | 3 | |
| 8 | 900 031 001 02 | WASHER8,4M >> W0 170 000 | 3 | 914-4/1,7914-1,8V/2,0 |
| 9 | 021 119 131 | WASHER | 1 | |
| 10 | 021 119 149 | CAP | 1 | 914-4/1,7 |
| (11) | 022 119 199 A | FAN HOUSINGM >> W0 129 581 | 1 | 914-4 |
| 11 | 021 119 199 D | FAN HOUSING M >>GB0 009 821M >>AN0 008 797M >> W0 250 000 | 1 | 914-1,7/1,8V914-1,8/2,0 |
| (11) | 021 119 199 D | FAN HOUSING M GB0 009 822>>M AN0 008 798>> | 1 | 914-1,8V/1,8914-2,0 |
| 12 | N 014 532 3 | STUDAM 8 A X 32 | 1 | |
| 13 | 311 405 381 | PLUG | 2 | |
| 14 | N 012 241 11 | SPRING WASHERB 8 X 15 | 3 | |
| 15 | N 010 244 11 | BOLT HEX-HD.M 8 X 30 | 3 | |
| 16 | 900 028 008 02 | SPRING WASHERB 6 | 8 | |
| 17 | N 010 719 2 | CHEESE-HD. SCREWAM 6 X 20 | 8 | |
| 18 | 021 119 233 A | COVER | 1 | |
| - | 021 119 249 E | MARKEDFORADJUSTMENTIGNITION POINT | 1 | 914-2,0 |
| 19 | 021 119 263 A | FLAP | 1 | |
| 20 | 021 119 264 A | FLAP | 1 | |
| - | 021 119 270 | PIN | X | |
| 21 | - | 62,55 MM | 2 | |
| (21) | - | 56 MM | 2 | |
| (22) | 021 119 281 D | COVER PLATEFORALTERNATORM >> W0 129 581 | 1 | 914-4 |
| 22 | 021 119 281 D | COVER PLATEFORALTERNATORM W0 129 582 >>M >>GB0 009 821M >>AN0 008 797M >> W0 250 000 | 1 | 914-1,7/1,8V914-1,8/2,0 |
| (22) | 022 119 281 | COVER PLATEFORALTERNATORM GB0 009 822>>M AN0 008 798>> | 1 | 914-1,8V/1,8914-2,0 |
| 23 | 021 119 295 01C | COVER | 1 | |
| 24 | 900 028 008 02 | SPRING WASHERB 6 | 1 | |
| 25 | N 010 346 5 | BOLT HEX-HD.BM 6 X 30 | 1 | |
| 26 | N 011 652 1 | WASHER7 | 1 | |
| 27 | N 014 139 5 | CHEESE-HD. SCREWAM 6 X 12 | 1 | |
| 28 | 022 119 512 | COVER PLATEFORENGINE | 1 | |
| 29 | N 011 652 1 | WASHER7 | 1 | |
| 30 | 999 072 005 09 | BOLT HEX-HD.M 6 X 12 | 1 | |
| 31 | 022 119 521 A | COVER PLATEFORENGINE | 1 | |
| 32 | N 011 652 1 | WASHER7 | 7 | |
| 33 | N 014 139 5 | CHEESE-HD. SCREWAM 6 X 12 | 7 | |
| 34 | 021 119 543 A | GASKETFRONTENGINE COVER650 MM | 2 | |
| 35 | 411 813 215 A | PROTECTIVE RUBBER | 1 | |
| 36 | 021 119 569 A | RUBBER GROMMET | 2 | 914-1,8V/1,8914-2,0 |
