Components
| No. | Part Number | Description | Qty. | Model |
|---|---|---|---|---|
| 1 | 901 108 125 01 | CARBURETOR40 IDT P 1 3 C 1CARBURETOR4 - 6 | 1 | |
| 2 | 901 108 126 01 | CARBURETOR40 IDT P 1 3 CCYLINDER1 - 3 | 1 | |
| 3 | 901 108 398 00 | GASKET | 6 | |
| 3 | 901 108 398 01 | GASKETWITHOUT ASBESTOSFORCARBURETOR | 6 | |
| 4 | 900 028 024 01 | SPRING WASHERB 8 X 15 | 16 | |
| 4/1 | 900 031 014 30 | WASHER8,4 | 12 | |
| 5 | 999 076 003 02 | NUT | 12 | |
| 5/1 | 999 084 601 02 | LOCKING NUTM 8 SNM 8 | 12 | |
| 6 | 901 108 039 04 | INTAKE MANIFOLDCOMPLETE | 1 | 901/36/38 |
| (6) | 905 108 031 04 | INTAKE MANIFOLDCOMPLETE | 1 | 901/37/39 |
| 6/1 | 999 703 076 50 | RUBBER GROMMETINTAKE MANIFOLD | 2 | |
| 7 | 901 108 040 13 | INTAKE MANIFOLDCOMPLETE | 1 | 901/36/37 |
| 8 | 900 061 007 02 | STUDBM 8 X 22 | 12 | |
| 9 | 900 061 022 01 | STUDM 8 X 12 | 4 | |
| 10 | 901 108 391 01 | GASKETFORINTAKE MANIFOLD | 12 | |
| 11 | 901 108 843 00 | LEVER | 1 | |
| 12 | 999 167 020 02 | BALL PIN | 1 | |
| 13 | 901 108 844 00 | LEVER | 1 | |
| 14 | 999 167 017 02 | BALL PIN | 1 | |
| 15 | 911 108 071 00 | CONTROL LEVERCOMPLETE | 1 | 901/36/37 |
| 16 | 900 028 024 01 | SPRING WASHERB 8 X 15 | 2 | |
| 17 | 900 034 001 02 | HEXAGON NUTBM 8 | 3 | |
| 18 | 999 076 003 02 | NUT | 4 | |
| 19 | 901 108 648 00 | PULL ROD | 1 | |
| 22 | 901 108 710 00 | REVERSE LEVER | 1 | 901/36/38 |
| (22) | 905 108 070 02 | REVERSE LEVER | 1 | 901/37/39:SPM |
| (22) | 901 108 720 00 | REVERSE LEVER | 1 | |
| 23 | 901 423 253 00 | BUSH | 2 | |
| - | 900 089 011 02 | WASHER4 | 1 | SPM |
| - | 900 028 018 02 | SPRING WASHERB 4 | 1 | SPM |
| - | 900 067 080 02 | CHEESE-HD. SCREWM 4 X 10 | 1 | SPM |
| 24 | 900 031 001 02 | WASHER8,4 | 2 | |
| 25 | 900 116 009 01 | LOCK WASHER6 | 2 | |
| 26 | 901 108 089 00 | PUSH RODCOMPLETE | 2 | |
| 27 | 900 169 010 02 | BALL SOCKETA 8LEFT | 2 | |
| 28 | 900 169 001 02 | BALL SOCKETA 8 | 4 | |
| 29 | 900 076 029 02 | HEXAGON NUTM 5LEFT | 2 | |
| 30 | 900 076 027 02 | HEXAGON NUTM 5 | 4 | |
| 31 | 901 108 631 00 | TENSION SPRING | 2 | |
| 32 | 900 028 018 02 | SPRING WASHERB 4 | 8 | |
| 33 | 900 014 073 02 | CHEESE-HD. SCREWM 4 X 10 | 8 | |
| 34 | 901 108 131 00 | INTERMEDIATE FLANGE | 6 | |
| 35 | 901 108 218 00 | GASKET | 2 | |
| 36 | 999 180 030 50 | FUEL HOSEC 7 X 1260 MM | * 2 | |
| 37 | 901 108 219 00 | CAP | 4 | |
| 38 | 911 110 391 00 | GASKET | 6 | |
| 39 | 911 108 322 01 | INTAKE TRUMPET | 6 | |
| 40 | 900 276 014 02 | LOCK NUTM 5 | 12 |
