Components
| No. | Part Number | Description | Qty. | Model |
|---|---|---|---|---|
| (1) | 369 06 149 | AIR GUIDE HOUSINGM >> 21 179M >> 30 529 | 1 | 356:13001500 |
| (1) | 546 06 010 | AIR GUIDE HOUSING | 1 | 356 A:1300 /S |
| 1 | 616 106 013 02 | AIR GUIDE HOUSINGBLACK | 1 | 1600 |
| (1) | 616 106 013 03 | AIR GUIDE HOUSINGSILVER | 1 | 1600 S |
| 2 | 539 06 116 | PLUG | 3 | |
| - | 999 703 013 50 | PLUGCOMPENSATING LINE | 1 | |
| 3 | 369 08 105 | BEARING BRACKETAIR GUIDE HOUSING | 3 | |
| 4 | 539 06 528 | RUBBER GROMMET | 3 | |
| 5 | 644 025 611 00 | RUBBER GROMMET | 3 | |
| 6 | 616 106 181 00 | NUTIMPELLER | 1 | |
| 7 | 616 106 011 00 | IMPELLER | 1 | |
| 8 | 546 06 204 | COVER DISC | 1 | |
| 9 | 546 06 202 | WASHER | X | |
| 10 | 546 06 203 | CARRIER PLATE | 2 | |
| 11 | 539 06 201 | HUB | 1 | |
| 12 | 539 06 102 | FLANGE | 1 | |
| 13 | 616 106 105 01 | COVER | 1 | |
| 14 | 900 075 009 02 | BOLT HEX-HD.M 6 X 10 | 6 | |
| 15 | 900 028 008 01 | SPRING WASHERB 6 | 4 | |
| 16 | 900 076 010 02 | HEXAGON NUTM 6 | 2 | |
| 17 | 546 06 590 | THERMOSTAT | 1 | |
| 18 | 900 075 025 02 | BOLT HEX-HD.M 8 X 15 | 1 | |
| 19 | 900 028 010 01 | SPRING WASHERB 8 | 1 | |
| 20 | 546 06 591 | CONNECTING RODUPPER | 1 | |
| 21 | 546 06 067 | CONNECTING RODLOWERWITHBALL SOCKETCLAMPING PIECEANDHEXAGON NUT | 1 | |
| 22 | 900 076 006 02 | HEXAGON NUTM 5 | 1 | |
| 23 | 900 169 002 02 | BALL SOCKETA 8 | 1 | |
| 24 | 900 074 011 02 | BOLT HEX-HD.M 6 X 18 | 1 | |
| 25 | 900 028 008 01 | SPRING WASHERB 6 | 1 | |
| 26 | 900 076 010 02 | HEXAGON NUTM 6 | 1 | |
| 27 | 546 06 065 | FLAP | 1 | |
| 28 | 546 06 062 | SOCKET | 2 | |
| 29 | 546 06 063 | VENTILATION TUBE | 1 | |
| (29) | 546 06 064 | VENTILATION TUBE | 1 | |
| (30) | 369 06 107 | LOWER PARTAIR DUCTCOMPLETE | 1 | 356 |
| 30 | 546 06 563 | LOWER PARTAIR DUCTCOMPLETE | 1 | 356 A |
| (30) | 369 06 111 | LOWER PARTAIR DUCTCOMPLETE | 1 | 356 |
| (30) | 546 06 564 | LOWER PARTAIR DUCTCOMPLETE | 1 | 356A |
| 31 | 539 06 541 | SPRING | 2 | |
| 32 | 539 06 644 | TENSION SPRING | 2 | |
| (33) | 369 06 130 | CONNECTING ROD | 1 | 356 |
| (33) | 369 06 131 | CONNECTING ROD | 1 | 356 |
| 33 | 539 06 572 | CONNECTING ROD | 2 | 356 A |
| 34 | 369 06 119 | COVER PLATEENGINE | 1 | |
| 35 | 369 06 133 | RUBBER MOLDING830 MM | 1 | |
| 36 | 539 06 605 | RUBBER GROMMET | 1 | |
| 37 | 539 06 518 | COVER PLATEFUEL PUMP | 1 | |
| 38 | 539 06 526 | COVER PLATEENGINE | 1 | |
| 39 | 539 06 645 | COVER PLATE | 1 | |
| 40 | 539 06 524 | COVER PLATE | 1 | |
| (41) | 369 06 122 | COVER PLATEENGINE | 1 | 356 |
| 41 | PCG 106 562 00 | COVER PLATEENGINEIT IS NECESSARY TO REWORK | 1 | 356 A |
| 42 | 369 06 139 | RUBBER MOLDING | 1 | |
| 43 | 539 06 637 | COVER PLATEUPPER | 1 | |
| (43) | 539 06 638 | COVER PLATEUPPER | 1 | |
| 44 | 539 06 639 | COVER PLATEUPPER | 1 | |
| (44) | 539 06 640 | COVER PLATEUPPER | 1 | |
| 45 | 539 06 646 | SUPPORTFORCOVER PLATE | 1 | |
| 46 | 900 075 009 02 | BOLT HEX-HD.M 6 X 10 | 2 | |
| 47 | 900 028 008 01 | SPRING WASHERB 6 | 2 | |
| (48) | 369 06 115 | COVER PLATE LATERAL | 2 | 356:110013001500/527 |
| 48 | 539 06 547 | COVER PLATELATERALFORCAST ELBOW528. 08.031/032 | 2 | 1600 /S |
| (48) | 502 06 117 | COVER PLATELATERALFORSHEET METAL ELBOW528. 08.033/034 | 2 | 528/1600 S |
| 9+50 | - | DELETED | * | |
| 51 | 900 075 009 02 | BOLT HEX-HD.M 6 X 10 | 6 | |
| 52 | 900 028 008 01 | SPRING WASHERB 6 | 6 | |
| 53 | 900 014 120 02 | CHEESE-HD. SCREWM 6 X 12 | 22 | |
| 54 | 900 025 004 02 | WASHERA 6,4 | 18 | |
| - | 999 025 108 02 | WASHER6,4 X 14 X 1,6 | 4 | |
| 55 | 369 06 140 | COVER PLATELATERAL | 1 | |
| (55) | 369 06 141 | COVER PLATELATERAL | 1 | |
| 56 | 369 06 137 | RUBBER MOLDING | 2 | |
| 56 | 369 06 139 | RUBBER MOLDING | 1 | |
| 57 | 506 06 105 | BAFFLE PLATE | 1 | |
| (57) | 506 06 106 | BAFFLE PLATE | 1 | |
| 58 | 506 06 108 | CLAMP | 2 |
