Components
| No. | Part Number | Description | Qty. | Model |
|---|---|---|---|---|
| (1) | 356 56 012 | FUEL TANK | 1 | |
| 1 | 644 201 010 00 | FUEL TANK50 L | 1 | |
| (1) | 356 56 013 | FUEL TANKF >> 53 526F >> 60 815 | 1 | COUPECABRIO |
| (1) | 356 56 013 1 | FUEL TANKF 53 527 >>F 60 816 >> | 1 | COUPECABRIO |
| 2 | 644 201 010 50 | FUEL TANK80 L | 1 | 356 A/540.1M |
| (2) | 644 56 015 | FUEL TANK72 L | 1 | 356M |
| 3 | 644 201 270 00 | COVER | 1 | 356 A/540.1 |
| (3) | 356 56 003 | COVER | 1 | 356 |
| 4 | 644 201 279 00 | SEALING RING | 1 | 356 A/540.1 |
| (4) | 356 56 114 | SEALING RING | 1 | 356 |
| 5 | 644 201 611 00 | VENT HOSE | 1 | 356 A/540.1 |
| (5) | 356 56 106 | VENT HOSE950 MM | 1 | 356 |
| 6 | 644 201 021 00 | SWITCHFUEL RESERVE INDICATOR50 L | 1 | 356 A/540.1 |
| (6) | 356 56 022 | SWITCHF >> 53 526F >> 60 815 | 1 | COUPECABRIO |
| (6) | 550 56 021 | SWITCHF 53 527 >>F 60 816 >> | 1 | COUPECABRIO |
| 7 | 644 201 021 50 | SWITCHFUEL RESERVE INDICATOR80 L | 1 | 356 A/540.1 |
| 8 | 644 201 291 00 | SEALING RING | 1 | 356 A/540.1 |
| (8) | - | SEALING RINGA 12 X 16F >> 53 526F >> 60 815 | 1 | COUPECABRIO |
| (8) | 550 56 217 | SEALING RING18 X 13 X 1,5F 53 527 >>F 60 816 >> | 1 | COUPECABRIO |
| 9 | 644 201 225 00 | STRAINERINSERT | 1 | 356 A/540.1 |
| (9) | 356 56 203 | STRAINERINSERTF >> 53 526F >> 60 815 | 1 | COUPECABRIO |
| (9) | 550 56 207 | STRAINERINSERTF 53 527 >>F 60 816 >> | 1 | COUPECABRIO |
| 10 | 644 201 221 00 | NUT | 1 | 356 A/540.1 |
| (10) | 356 56 207 | NUTF >> 53 526F >> 60 815 | 1 | COUPECABRIO |
| (10) | 550 56 206 | NUTF 53 527 >>F 60 816 >> | 1 | COUPECABRIO |
| 11 | 644 201 292 00 | SEALING WASHER | 1 | 356 A/540.1 |
| (11) | 356 56 108 | SEALING WASHERF >> 53 526F >> 60 815 | 1 | COUPECABRIO |
| (11) | 550 56 212 | SEALING WASHERF 53 527 >>F 60 816 >> | 1 | COUPECABRIO |
| 12 | 644 201 203 00 | SEALING RING | 1 | 356 A/540.1 |
| (12) | 356 56 208 | SEALING RINGF >> 53 526F >> 60 815 | 1 | COUPECABRIO |
| (12) | 550 56 216 | SEALING RINGF 53 527 >>F 60 816 >> | 1 | COUPECABRIO |
| 13 | 644 201 204 00 | FILTER | 1 | 356 A/540.1 |
| (13) | 356 56 209 00 | FILTERF >> 53 526F >> 60 815 | 1 | COUPECABRIO |
| (13) | 550 56 215 | FILTERF 53 527 >>F 60 816 >> | 1 | COUPECABRIO |
| 14 | 644 201 205 00 | FILTER | 1 | 356 A/540.1 |
| (14) | 356 56 210 00 | CONTAINERF >> 53 526F >> 60 815 | 1 | COUPECABRIO |
| (14) | 550 56 214 | CONTAINERF 53 527 >>F 60 816 >> | 1 | COUPECABRIO |
| 15 | 644 201 206 00 | LOCK RING | 1 | 356 A/540.1 |
| (15) | 356 56 205 | LOCK RINGF >> 53 526F >> 60 815 | 1 | COUPECABRIO |
| (15) | 550 56 218 | LOCK RINGF 53 527 >>F 60 816 >> | 1 | COUPECABRIO |
| (16) | 644 201 207 00 | GASKET$ 22 MM | 1 | 356 A/540.1 |
| 16 | 644 201 293 00 | GASKET$ 26 MM | 1 | 356 A/540.1 |
| (16) | 356 56 206 | GASKETF >> 53 526F >> 60 815 | 1 | COUPECABRIO |
| (16) | 550 56 219 | GASKETF 53 527 >>F 60 816 >> | 1 | COUPECABRIO |
| 17 | 644 201 231 50 | SEALING RINGTUBE | 1 | 356 A/540.1 |
| 18 | - | DELETED | X | |
| 19 | 644 201 243 00 | HOSE PIECEOPERATING ROD | 1 | 356 A/540.1 |
| (19) | 356 56 107 | HOSE PIECEOPERATING ROD | 1 | 356 |
| 20 | 644 201 261 00 | STICKER | 1 | 356 A/540.1 |
| (20) | 356 56 102 | STICKER | 1 | 356 |
| 21 | 900 016 002 00 | HALF-ROUND SCREWM 4 X 10 | 1 | |
| 22 | 900 076 002 02 | HEXAGON NUTM 4 | 1 | |
| 23 | 644 201 241 00 | OPERATING RODFORSWITCH | 1 | 356 A/540.1 |
| (23) | 356 56 101 | OPERATING RODFORSWITCH | 1 | 356 |
| 24 | 644 025 611 00 | RUBBER GROMMET | 1 | 356 A/540.1 |
| (24) | 356 56 105 | RUBBER GROMMET | 1 | 356 |
| 25 | 900 021 011 00 | COTTER PIN3 X 22 | 2 | |
| 26 | 999 180 020 50 | FUEL HOSE | * | 356 A/540.1 |
| 27 | 616 108 531 00 | FUEL LINE1860 MM | 1 | 356 A/540.1 |
| 28 | 356 49 648 | CLIP | 1 | 356 A/540.1 |
| (28) | 900 172 001 00 | CLAMP | 1 | 356 A/540.1 |
| 29 | 900 074 005 02 | BOLT HEX-HD.M 5 X 22 | 2 | 356 A/540.1 |
| 30 | 900 028 007 01 | SPRING WASHERB 5 | 2 | 356 A/540.1 |
| 31 | 900 076 004 02 | HEXAGON NUTM 5 | 1 | 356 A/540.1 |
| - | 356 49 664 | BOOT | 1 | 356 A/540.1 |
| 32 | 914 356 201 00 | RUBBER GROMMET | 1 | 356 A/540.1 |
| 33 | 999 180 020 50 | FUEL HOSE | 1 | 356 A/540.1 |
| 34 | 999 706 009 80 | SUSPENSION STRAP | 1 | 356 A/540.1 |
| 35 | 644 201 621 00 | TAIL PIPEVENTILATION | 1 | 356 A/540.1 |
| 36 | 999 702 020 50 | RUBBER GROMMET8 X 12 X 9 | 1 | 356 A/540.1 |
| (37) | 356 70 141 | SENDERFOR-BECK-FUEL INDICATOR | 1 | 356 |
| (37) | 356 56 135 | SENDERFOR-VDO-KE 303F 53 527 >>F 60 816 >> | 1 | 356 |
| 37 | 644 201 801 00 | SENDERFUEL INDICATOR | 1 | 356 A/540.1 |
| (38) | 914 201 891 00 | GASKET-VDO-F 53 527 >>F 60 816 >> | 1 | 356 |
| (38) | 644 201 891 00 | GASKET | 1 | 356 A |
| 38 | 644 201 891 06 | GASKET | 1 | 356 A/540.1 |
| 39 | 900 015 012 02 | SCREW FILL. HD.M 5 X 15 | 5 | 356 A/540.1 |
| 40 | 900 025 003 30 | WASHER5,3ALUMINIUM | 5 | 356 A/540.1 |
| - | 356 08 294 | HOSE$ 7 MM250 MMLONGFORFUEL LINE | 1 | 356 |
| - | 356 08 295 | HOSE$ 7 MM150 MMLONGFORFUEL LINE | 1 | 356 |
| - | 356 49 670 | FUEL LINE$ 8 MM(CU)2400 MM | 1 | 356 |
