Components
| No. | Part Number | Description | Qty. | Model |
|---|---|---|---|---|
| 1 | 547 06 301 | ENGINE COVER | 1 | |
| 2 | 547 06 311 | ENGINE COVER | 1 | |
| (2) | 547 06 312 | ENGINE COVER | 1 | |
| 3 | 547 06 310 | ENGINE COVER | 1 | |
| 4 | 547 06 321 | STRUT | 1 | |
| 5 | 547 06 322 | STRUT | 1 | |
| - | 900 075 011 00 | BOLT HEX-HD.M 6 X 15 | 6 | |
| - | 900 075 010 00 | BOLT HEX-HD.M 6 X 12 | 2 | |
| - | 900 027 013 00 | LOCK RINGB 6 | 8 | |
| - | 900 076 010 00 | HEXAGON NUTM 6 | 2 | |
| 6 | 547 06 306 | GASKETUPPER | 1 | |
| 7 | 547 06 308 | RUBBER MOLDING1925 MMLONG | 1 | |
| 8 | 547 06 325 0 | SEALING RUBBER | 1 | |
| 9 | 999 702 040 50 | RUBBER GROMMET | 1 | |
| 10 | 539 09 201 | RUBBER CAP | 2 | |
| 11 | 547 06 533 | LOWER PARTAIR DUCT | 1 | |
| (11) | 547 06 534 | LOWER PARTAIR DUCT | 1 | |
| 12 | 547 06 051 | COVER PLATEWITHCONNECTING PIECE | 1 | |
| (12) | 547 06 052 | COVER PLATEWITHCONNECTING PIECE | 1 | |
| 13 | 547 06 053 | COVER PLATE | 1 | |
| (13) | 547 06 556 | COVER PLATE | 1 | |
| 14 | 547 06 557 | FILLER PLATE | 1 | |
| (14) | 547 06 558 | FILLER PLATE | 1 | |
| 15 | 547 06 504 | INTAKE MANIFOLDCOVER PLATE | 2 | |
| 16 | 547 06 516 | BAFFLE PLATEUPPER | 2 | |
| 17 | 547 06 517 | BAFFLE PLATELOWER | 2 | |
| 18 | 547 06 518 | SPRING CLIP | 2 | |
| - | 900 028 003 00 | SPRING WASHERB 6 | 18 | |
| - | 900 015 013 00 | LENS-HD. SHEET METAL SCREWM 6 X 10 | 18 | |
| - | 900 075 011 00 | BOLT HEX-HD.M 6 X 15 | 20 | |
| - | 900 028 003 00 | SPRING WASHERB 6 | 20 | |
| 19 | 547 06 017 10 | AIR GUIDE HOUSINGWITHDC GENERATORCOMPLETE | 1 | |
| 20 | 547 06 015 | AIR DUCT | 1 | |
| 21 | 547 06 016 | AIR DUCT | 1 | |
| 22 | 547 06 012 | INSERTRINGCOMPLETE | 1 | |
| 23 | 900 016 012 00 | HALF-ROUND SCREWM 6 X 15 | 7 | |
| 24 | 900 016 013 02 | HALF-ROUND SCREWM 6 X 28 | 1 | |
| - | 900 015 013 02 | SCREW FILL. HD.M 6 X 10 | 27 | |
| - | 900 028 003 00 | SPRING WASHERB 6 | 35 | |
| 25 | 547 006 501 00 | DECALCOMANIA LABELENGINE SPECIFICATIONS | 1 | |
| 26 | 547 06 021 | IMPELLER | 1 | |
| 27 | 547 06 209 | PROTECTIVE CAP | 1 | |
| 28 | 547 06 210 | HEXAGON NUT | 1 | |
| 29 | 900 030 001 00 | LOCK PLATE13 | 1 | |
| 30 | 900 019 011 02 | TAPP. SCREW CSK.-RAISED HDM 6 X 30 | 1 | |
| 31 | 547 01 110 | RETAINER | 1 | |
| 32 | 547 01 111 | CONE RING | 1 | |
| 33 | 547 01 120 | LOCK RING | 1 | |
| - | 900 028 010 00 | SPRING WASHERB 8 | 4 | |
| - | 502 08 310 | HEXAGON NUT | 4 | |
| 34 | 547 08 103 | RETAINING PIVOT | 1 | |
| 35 | 547 01 109 | BRACKET | 1 | |
| 36 | - | SEE GROUP9/01/05 | * |
