Components
| No. | Part Number | Description | Qty. | Model |
|---|---|---|---|---|
| 1 | - | CAMSHAFTALTERNATIVE PARTS: | X | 1300/1600 |
| - | 616 105 011 00 | CAMSHAFTCOMPLETEWITHGEARSIZE 0 | 1 | 1300/1600 |
| - | 616 105 011 10 | CAMSHAFTCOMPLETEWITHGEAR-1 | 1 | 1300/1600 |
| - | 616 105 011 20 | CAMSHAFTCOMPLETEWITHGEAR-2 | 1 | 1300/1600 |
| - | 616 105 011 30 | CAMSHAFTCOMPLETEWITHGEAR+1 | 1 | 1300/1600 |
| - | 616 105 011 40 | CAMSHAFTCOMPLETEWITHGEAR+2 | 1 | 1300/1600 |
| (1) | - | CAMSHAFT ALTERNATIVE PARTS: | X | 1300 S1600 S |
| - | 616 105 012 00 | CAMSHAFTCOMPLETEWITHGEAR0 | 1 | 1300 S1600 S |
| - | 616 105 012 10 | CAMSHAFTCOMPLETEWITHGEAR-1 | 1 | 1300 S1600 S |
| - | 616 105 012 20 | CAMSHAFTCOMPLETEWITHGEAR-2 | 1 | 1300 S1600 S |
| - | 616 105 012 30 | CAMSHAFTCOMPLETEWITHGEAR+1 | 1 | 1300 S1600 6 |
| - | 616 105 012 40 | CAMSHAFTCOMPLETEWITHGEAR+2 | 1 | 1300 S1600 S |
| 2 | - | GEARALTERNATIVE PARTS: | X | |
| - | 616 105 103 01 | GEAR | 1 | |
| ALUMINIUM | ||||
| - | 616 105 103 11 | GEAR-1ALUMINIUM | 1 | |
| - | 616 105 103 21 | GEAR-2ALUMINIUM | 1 | |
| - | 616 105 103 31 | GEAR+1ALUMINIUM | 1 | |
| - | 616 105 103 41 | GEAR+2ALUMINIUM | 1 | |
| 3 | 999 039 001 00 | LOCK PLATE | 3 | |
| 4 | 900 075 024 00 | BOLT HEX-HD.M 8 X 13 | 3 | |
| 4 | 900 075 453 00 | BOLT HEX-HD.M 8 X 16 | 3 | |
| 5 | 900 012 010 00 | DOWEL PIN6 X 12 | 3 | |
| 6 | 616 105 201 00 | CAM FOLLOWER | 8 | 1300/1600 |
| (6) | 539 05 210 | CAM FOLLOWER | 8 | 1300 S1600 S |
| 7 | 616 105 028 02 | PUSH RODFOR CYLINDER GREY CAST IRON | 8 | 1600/1600 S |
| (7) | 616 105 026 00 | PUSH RODFOR CYLINDERALUMINIUM | 8 | |
| 8 | 616 105 231 00 | PROTECTIVE TUBE | 8 | |
| 9 | 539 05 207 | GASKET | 8 | |
| 10 | 539 05 223 | ROCKER ARM BRIDGE | 2 | |
| 11 | 539 05 225 | ROCKER SHAFTLONG | 2 | |
| 12 | 539 05 226 | ROCKER SHAFTSHORT | 4 | |
| 13 | 369 05 271 | ROCKER ARM | 4 | |
| 14 | 539 05 218 | ROCKER ARMLONG | 2 | |
| 15 | 539 05 219 | ROCKER ARMSHORT | 2 | |
| 16 | 539 05 205 | SPRING | 2 | |
| 17 | 539 05 235 | THRUST WASHER0,50 MM | X | |
| (17) | 539 05 236 | THRUST WASHER0,40 MM | X | |
| (17) | 539 05 237 | THRUST WASHER0,60 MM | X | |
| 18 | 900 041 007 01 | LOCK RING16 X 1 | 12 | |
| 19 | 900 158 002 00 | HEXAGON NUTM 8 X 1 | 8 | |
| 20 | 369 05 243 | ADJUSTING SCREW | 8 | |
| 21 | 900 074 061 00 | BOLT HEX-HD.M 10 X 48 | 4 | |
| 22 | 900 028 005 01 | SPRING WASHER | 4 |
